Frame   FORM™ Alloy | Integrated Display | Mid-High Pivot Smoothlink Suspension System | Press Fit BB | RIDE-2™ Adjustable Geometry | 130mm Travel. FORM™ Alloy Rear Triangle

Fork   RockShox Reba R 140mm | 40m Offset

Shock   RockShox Deluxe Select | Sealed Bearing Eyelet | 20x8mm F Hardware | 170x35mm

Grips   SGD Slater JR Lock On

Stem   Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm

Headset   FSA ZS56|66 Reach Adjust| 5mm Cups Installed | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5"" Crown Race

Stem   Rocky Mountain 31.8 AM | 5° Rise | All Sizes = 40mm

Handlebar   Rocky Montain Jr | 640mm Width |25mm rise | 9° Backsweep |5° Upsweep | 31.8 | For 19mm Grips

Grips   SGD Slater JR Lock On

Brakes   Tektro HD-J285 | Short Reach Lever | Shimano Pad Compatible

Shifters   Shimano CUES 10spd

Rear Derailleur   Shimano CUES 10spd

Cranks & Chainring   Rocky Mountain Microdrive 2PC | 30T | SRAM Direct Mount | 24mm Spindle | Crank Length: 155mm

Bottom Bracket   Rocky Mountain Sealed - Shimano Compatible

Cassette   Shimano CUES 11-48T 10spd

Chain   KMC X11-1

Front Hub   Shimano TC500 | 15x100m | 28H

Rear Hub   Shimano TC500 Boost 148mm | 28H

Spokes   2.0 Stainless

Rims   WTB ST Light i27 TCS 2.0 Tubeless | 28H / Tubeless Ready - Tape / Valves Incl

Tires   F: Maxxis Minion DHF 2.4 WT EXO Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT EXO Tubeless Ready //

Seatpost   X Fusion Manic Composite 30.9mm | 125mm

Saddle   Rocky Mountain Kids

Weight NW   19.03 KGS

Electrical Components

Drive System   Dyname S4 Mini Mountain Bike Drive | 300W Max Power | 250W Nominal Power | 40Nm | Rocky Mountain Micro Remote | Low RPM - High Efficiency class 1 eMTB System | Designed in Canada

Battery   240 Wh Fully Integrated Li-Ion

Remote   Rocky Mountain Micro Remote

Display   Rocky Mountain Jumbotron | Drive System Customization | Battery & Assist Level | Trip | Speed | Cadence | Top Tube Integration

Charger   Rocky Mountain Powerplay Charger V2 | 2A | 48V | Higo Deep Socket Connector | Overtimepack Compatible (Dyname 4)
