ZEB is built for the most extreme terrain—steep double-black runs, freeride features, and even the pedal back up if that’s in the cards. The all-new LinearXL air spring delivers a coil-like ride—supple off the top, supportive through the mid-stroke, and backed by a fixed bottom-out system for confident end-stroke control—giving you unwavering consistency and predictability. The Delta RC damper features an intuitive Compression adjustor, making setup fast, understandable, and easy to communicate. ZEB delivers the composure riders need to confidently pick their line and hold it—no matter how extreme the trail.

Features

• NEW LinearXL air spring delivers a consistent and predictable ride feel backed by afixed bottom-out system for end-stroke control
• NEW Delta RC damper with easy-to-adjust Compression and independent Rebound features intuitive controls and virtually silent performance, keeping riders focused on the trail
• NEW Integrated short fender mount (ZEB Integrated Fender included)
• Low-grab SKF wiper seals deliver long-lasting fork performance and a smoother ride
• Maxima 920 blended 15w reduces overall fork friction

Wheel size     27.5"
Travel (mm)     150mm, 160mm, 170mm, 180mm
Damper Type     Delta RC
Fork offset      44mm (27.5")
Color (FS)     Diffusion Black, Gloss Black
E-Bike Approved     E-bike Approved, E-bike Approved w/E-MTB Decal
Steerer     1.5" Tapered, 1.8" Tapered
Axle     15x110mm BOOST™ TC Compt
Upper tube type     38mm aluminum
Damper adjust     Crown
Volume reducer     0/3 Tokens, 0/4 Tokens, 1/4 Tokens, 1/5 Tokens
Spring     LinearXL
Max Tire Width (mm)     74.5
Maximum Rotor Size     220mm
Minimum Rotor Size     200mm
Fender Compatibility     Yes  (not included)
