Frame     SMOOTHWALL™ Carbon | Full Sealed Cartridge Bearings | Press Fit BB | Internal Cable Routing | 2-Bolt ISCG05 Tabs | RIDE-9™ Adjustable Geometry | 2 Position Axle | 160mm Travel. SMOOTHWALL™ Carbon Rear Triangle
Fork     Fox 38 Float EVOL GRIP2 Factory Series 170mm | 27.5 = 37mm Offset | 29 = 44mm Offset
Rear Shock     Fox Float X2 Factory | Sealed Bearing Eyelet | 25x8mm F Hardware | SM = 210x55mm | MD - LG - XL = 230x60mm | Size-Specific tune in FAQ
Handlebars     Race Face Next R | 780mm Width | 35mm Rise | 8° Backsweep | 4° Upsweep | 35mm Clamp
Grips     ODI Elite Pro Lock On
Stem     Race Face Turbine R | 0° Rise | All Sizes = 40mm
Seatpost     Fox Transfer Factory Series 30.9mm | SM = 125mm | MD = 150mm | LG = 175mm | XL = 200mm
Saddle     WTB Volt Race 142
Shifters     Shimano XTR
Rear Derailleur     Shimano XTR
Brakes     Shimano XTR Trail 4 Piston | IceTec Metal Pads | F:Shimano RT86 203mm | R:Shimano RT86 203mm
Cassette     Shimano XTR 12s 10-51T
Cranks & Chainring     Race Face Turbine Cinch | 32T | 30mm Spindle | 170mm Crank Length
Chain     Shimano XTR 12s
Bottom Bracket     Race Face BB92 30mm
Headset     FSA Orbit NO.57E | Sealed Stainless 36°x45° Bearings | 30.2mm x 41mm x 7.1mm Upper | 40mm x 51.8mm x 7.5mm Lower | 1.5"" Crown Race
Front Hub     DT Swiss 350 Boost 15mm
Rear Hub     DT Swiss 350 Boost 148mm | 36T Star-Ratchet
Spokes     DT Swiss Competition 2.0/1.8/2.0
Tires     F: Maxxis Assegai 2.5 WT 3C MaxxGrip DD Tubeless Ready // R: Maxxis Minion DHR II 2.4 WT 3C MaxxTerra DD Tubeless Ready
Rims     Race Face ARC Carbon 31 | 32H | Tubeless Ready - Tape / Valves Incl
Weight NW     This information isn't available yet. We will update the weight of this model as soon as possible.
